Today, we are embarking on a fun project. At STH, we have been pushing for and have started to see 2.5GbE become much more commonplace in devices. Those devices include PCs, WiFi APs, cable modems, routers, and more. One of the biggest challenges today is that getting 2.5GbE switches is too expensive, and there are not enough good options. As a result, we decided to buy every cheap 2.5GbE switch we could find on Amazon and a few on AliExpress and do a round-up. Now, we have the Ultimate Cheap 2.5GbE switch guide.

Ultimate Cheap 2.5GbE Switch Guide Overview and Video

Here is the new 2024 video where we tested 21 different switches.

Here is the original video that goes along with this piece.

Over the next few weeks, we are going to have formal reviews of each unit in the round-up on STH. One of the biggest challenges with reviewing 15 switches (plus a bonus) for something like this is that by the time we had received all of the units, tested them, aggregated results, then recorded the video, new units have come out. We will add those to this guide as we go, so feel free to save it for future reference.

We are going to introduce a few main categories:

  • 5-port 2.5GbE Unmanaged Switches
  • 8-port 2.5GbE Unmanaged Switches
  • 10Gbase-T Capable 2.5GbE Switches
  • 4-port 2.5GbE and 2-port SFP+ Switches
  • 5-port 2.5GbE and SFP+ Switches
  • 8-port 2.5GbE and 2-port SFP+ 10GbE Switches
  • 8-port 2.5GbE and 2-port SFP 2.5G Switches
  • 8-port 2.5GbE and 1-port SFP+ 10GbE Switches
  • PoE Capable Switches
  • Inexpensive Managed 2.5GbE Switches with Fans

We are also going to note when we find switches in each category that are managed. At this point, most are unmanaged, but we had two in our first 15 already that are managed switches. The prices change, so we are using what we paid in Q1 2023 when we purchased the initial set of units.

5-port 2.5GbE Fanless Switches

Our Choice: QNAP QSW-1105-5T

QNAP QSW 1105 5T Front For Guide
QNAP QSW 1105 5T Front For Guide

Notes: Our pick here is the QNAP QSW-1105-5T. It has the best balance of initial cost, power consumption, and regulatory markings/ certifications. The Netgear MS105 and MS305 are virtually identical, except for the paint job and warranty.

8-port 2.5GbE Fanless Unmanaged Switches

Our Choice: Toss-up

TP Link TL SH1008 Ports Three Quarter
TP Link TL SH1008 Ports Three Quarter

Notes: The TRENDnet TEG-S380 is a better value than the TEG-S350 (5-port) often. There was only a $5 difference between the two switches when we recorded the video. The TP-Link TL-SH1008 we only found on AliExpress and lacks common NA/ EU regulatory markings. The TP-Link is the better price, but the TRENDnet is better if you are looking for regulatory markings and certifications.

TRENDnet TEG S380 Front
TRENDnet TEG S380 Front

10Gbase-T Capable Fanless 2.5GbE Switches

Our Choice: QNAP QSW-2104-2T-A

QNAP QSW 2104 2T A 4x 2.5GbE 2x 10Gbase T Switch Front
QNAP QSW 2104 2T A 4x 2.5GbE 2x 10Gbase T Switch Front
  • TRENDnet TEG-S762 (Amazon Affiliate Link)
    • 4x 2.5GbE, 2x 10Gbase-T
    • Unmanaged
    • 4.4W idle, 0.3-0.4W per 2.5GbE Port
    • $190 when tested
  • QNAP QSW-2104-2T-A (Amazon Affiliate Link)
    • 4x 2.5GbE, 2x 10Gbase-T
    • Unmanaged
    • 4.0W idle, 0.4W per 2.5GbE Port, 1.0-1.4W per 10Gbase-T Port
    • $149 when tested
  • Hasivo S600W-4GT-1SX-1XGT (AliExpress Affiliate Link)
    • 4x 2.5GbE, 1x 10Gbase-T, 1x SFP+
    • Smart Managed, Unmanaged Optional
    • 1.3W Idle, 1W per 2.5GbE Port
    • $89 when tested
  • Mokerlink 2G04210GSMX (Amazon Affiliate Link)
    • 4x 2.5GbE, 1x 10Gbase-T, 1x SFP+
    • Smart Managed, Unmanaged Optional
    • 1.3W Idle, 1W per 2.5GbE Port
    • $96 when tested

Notes: The first two switches appear to be identical internally. QNAP has a more power-efficient AC adapter and is usually found for 20% less (or more) than the TRENDnet making it the easy recommendation. The second two are also identical, but Hasivo is on AliExpress, and Mokerlink is on Amazon. We will quickly note that the Hasivo also has a PoE version available.

4x 2.5GbE and SFP+ 10GbE Capable Fanless 2.5GbE Switches

Our Choice: ienRon HG0402XG

IenRon HG0402XG Front
IenRon HG0402XG Front

Notes: This is a super competitive space. Our choice largely comes down to the cost of the switches when tested. The QNAP QSW-2104-2S-A is the TRENDnet TEG-S762 except with SFP+ instead of 10Gbase-T. For $130 and with regulatory markings, the QNAP is a solid value. The XikeStor adds web management.

5x 2.5GbE and SFP+ 10GbE Fanless Switches

Our Choice: Hasivo S600WP-5GT-2S+_SE

Hasivo S600WP 5GT 2S+ For Guide
Hasivo S600WP 5GT 2S+ For Guide
  • MokerLink 2G05210GSM (Amazon Affiliate Link)
    • 5x 2.5GbE, 2x SFP+ 10GbE
    • Managed
    • 5.0W idle, 0.7W per 2.5GbE Port
    • $189 when tested
  • MokerLink 2G05110GS (Amazon Affiliate Link)
    • 5x 2.5GbE, 1x SFP+ 10GbE
    • Unmanaged
    • 1.0W idle, 1.0W per 2.5GbE Port
    • $72 when tested – Similar to YuLinca below
  • YuLinca 2G06110GS (Amazon Affiliate Link)
    • 5x 2.5GbE, 1x SFP+ 10GbE
    • Unmanaged
    • 1.0W idle, 0.3W per 2.5GbE Port
    • $50 when tested – Similar to MokerLink above
  • Sodola SL-SWTG015AS (Amazon Affiliate Link)
    • 5x 2.5GbE, 1x SFP+ 10GbE
    • Unmanaged
    • 1.0W idle, 1.0W per 2.5GbE Port
    • $70 when tested
  • Nicgiga S250501 (Amazon Affiliate Link)
    • 5x 2.5GbE, 1x SFP+ 10GbE
    • Unmanaged
    • 1.0W idle, 1.0W per 2.5GbE Port
    • $70 when tested
  • Nicgiga S250501-M (Amazon Affiliate Link)
    • 5x 2.5GbE, 1x SFP+ 10GbE
    • Web managed
    • 1.0W idle, 0.3W per 2.5GbE Port
    • $59 when tested
  • Hasivo S600WP-5GT-2S+SE (AliExpress Affiliate Link)
    • 5x 2.5GbE, 2x SFP+ 10GbE
    • Managed. PoE on Port 1, PoE+ on Ports 2-4, No PoE Port 5
    • 7.1W idle, 1W per 2.5GbE Port
    • $165 when tested

Notes: The MokerLink 2G05210GSM and Hasivo S600WP-5GT-2S+_SE are the two managed switches and have very similar chassis and management interfaces. The Hasivo adds PoE/ PoE+ and is priced lower so that gets our recommendation. Still, some users have reported that the switches, on some firmware versions, can lose things like DHCP settings on reboot.

8x 2.5GbE and 2x SFP+ 10GbE Capable Fanless 2.5GbE Switches

Our Choice: Gigaplus 8x 2.5GbE and 2x SFP+

  • Gigaplus GP-S250802 (Amazon Affiliate Link)
    • 8x 2.5GbE, 2x SFP+ 10GbE
    • Unmanaged
    • 2.,0W idle, 0.6W per 2.5GbE Port
    • $69 when tested
  • TRENDnet TEG-3102WS (Amazon Affiliate Link)
    • 8x 2.5GbE, 2x SFP+ 10GbE
    • Managed
    • 5.6W idle, 1.4W per 2.5GbE Port
    • $215 when tested

Notes: The Gigaplus can often be found for only slightly more than models with a single SFP+ port. In our second round-up, the TRENDnet had perhaps the best management interfaces of any of the switches but cost considerably more.

8x 2.5GbE and 2x 2.5G SFP Capable Fanless 2.5GbE Switches

  • Tenda TEM2010F (Amazon Affiliate Link)
    • 8x 2.5GbE, 2x SFP 2.5GbE
    • Unmanaged, port isolation feature via physical switch
    • $119 when tested

This Tenda unit is a strange little switch with some different port isolation features. Still, it is the only 10-port 2.5GbE switch that we found. The big question is whether this is a better option than the 8+2 units.

8x 2.5GbE and 1x SFP+ 10GbE Capable Fanless 2.5GbE Switches

Our Choice: Sodola 8x 2.5GbE and 1x SFP+

Sodola 8x 2.5GbE 1x 10GbE Switch Front
Sodola 8x 2.5GbE 1x 10GbE Switch Front

Note: We have an entire video talking about these, but have reviewed several more units since then.

The new 8x 2.5GbE and 1x SFP+ switches came out after we did the original guide. The Horaco is the least expensive, but it is also the only one we had an issue with and it took more than two weeks longer to arrive than the Amazon ones. Video for those four switches above. Now, some new offerings from companies like YuanLey and Davuaz are pushing prices down considerably to well under $100.

PoE Capable Fanless 2.5GbE Switches

Our Choice: Hasivo S1100P-8GT, Netgear MS108UP

Hasivo S1100P 8GT Atop TP Link Switches Priced Similarly
Hasivo S1100P 8GT Atop TP Link Switches Priced Similarly
  • Hasivo S1100P-8GT Review (AliExpress Affiliate Link)
    • 8x 2.5GbE
    • Unmanaged. PoE varies by port. It seems to mostly support PoE/PoE+ but we can get some ports to power PoE++. See review.
    • 6.5W idle, 1.7W per 2.5GbE Port
    • $123 when tested
  • Sodola SL-SGT108-P (Amazon Affiliate Link)
    • 8x 2.5GbE
    • Unmanaged. PoE varies by port. It seems to mostly support PoE/PoE+ but we can get some ports to power PoE++ similar to Hasivo.
    • 7.1W idle, 1.7W per 2.5GbE Port
    • $100 when tested
  • Hasivo S600-5GT Review (AliExpress Affiliate Link)
    • 5x 2.5GbE
    • Unmanaged. PoE varies by port. It seems to mostly support PoE/PoE+ but we can get some ports to power PoE++. See review.
    • 6.5W idle, 1.7W per 2.5GbE Port
    • $149 when tested
  • Netgear MS108UP Review (Amazon Affiliate Link)
    • 8x 2.5GbE
    • Unmanaged. 4x PoE+ and 4x PoE++. See review.
    • 6.8W idle, 1.4W per 2.5GbE Port
    • $239 when tested
  • Hasivo S600WP-4GT-1SX-1XGT-SE (AliExpress Affiliate Link)
    • 4x 2.5GbE, 1x 10Gbase-T, 1x SFP+
    • Smart Managed, Unmanaged Optional. 4x PoE
    • 2.3W Idle, 1W per 2.5GbE Port
    • $119 when tested

Notes: The Netgear MS108UP has four PoE++ ports and four PoE+ so this is perhaps the most capable PoE switch. The Hasivo S1100P-8GT is perhaps a better value than the 8-port non-PoE switches. The S600-5GT is a pass given its cost/ features.

Netgear MS108UP Front Angle 1
Netgear MS108UP Front Angle 1

Larger Fanless 2.5GbE Switches

Our Choice: TP-Link TL-SH1832

TP Link TL SH1832 Front 2
TP Link TL SH1832 Front 2

This is a larger switch, but it is also the lowest cost per port in our review.

Inexpensive Managed 2.5GbE Switches with Fans

Our Choice: MikroTik CRS310-8G+2S+IN

MikroTik CRS310 8G 2S IN Front
MikroTik CRS310 8G 2S IN Front

Final Words

Hopefully, this guide helps folks narrow down which switch is the best in a given class. We are going to keep adding to this. Folks may notice that the video released on the same day as this Buyer’s Guide has one fewer switch, and we also now have two more switches that are not on the list above. Our plan is to make this a guide over time and then to have the reviews of the individual switches. Bookmark and share this as we are making a big resource here.

A quick note that we have seen with various lower-end switches over the years is that internal components can change over time. We are going to try keeping this fresh, but if you saw our Netgear Making Simple PoE Switches too Complex you will see the challenge.
