MikroTik RDS2216-2XG-4S+4XS-2XQ Block Diagram
The MikroTik RDS2216-2XG-4S+4XS-2XQ has a wild block diagram. The easy part is the Marvell 98DX4310 switch chip that has 16 ports, twelve of which go to the rear network ports. Four of those ports, however, go to the Annapurna Labs CPU which means we have 100Gbps between the two. That is important since it limits our storage performance to 100Gbps maximum. We also see those numbers decrease if you are offloading networking functions to the CPU from the switch chip.
The PCIe switch has that PCIe Gen3 x16 link over the side PCB. It then breaks out those 16 lanes to 40 lanes for x2 per drive. That means the maximum per drive performance is in the ~12-15Gbps range. Think of the NVMe storage being there more for capacity and having a number of devices rather than for speed.
The M.2 SATA drives are also only SATA II 3.0Gbps not SATA III 6.0Gbps. We purchased some ultra cheap Silicon Power A55 drives to stick in there. (Amazon Affiliate link.)
Next, let us get to the software.
MikroTik RDS2216-2XG-4S+4XS-2XQ Software
MikroTik has a “ROSE Edition” of its standard management suite. You have the option of the console CLI, the WinBox application, or the 192.168.88.1 reachable web GUI. The web GUI is certainly more green in the ROSE edition. Perhaps the most challenging thing from a hardware perspective is the software side. This is a system that is designed to run NAS applications. Perhaps you want to run a Minio server, a simple SMB network share, or even a Nextcloud/ Owncloud server. In the MikroTik world, the idea is that you would use a container.
Still, when you search for docker or container in the interface, that is not there.
Likewise, if you want to setup a SMB share, RAID across the 20 or 22 SSDs, and so forth, the current option is to go to the CLI. Sometimes, the options are also confusing like there is an option to eject the PCIe switch on the NVMe backplane from the web UI. While you can do what you need, and even export drives as TCP NVMe drives (and setup RAID on the remote host) it is a giant pain. We went over this in detail in the video chapter on software.
Aside from that, there are few options for in-context menus. So SMB users who just want to make a NAS RAID array and export it as a SMB 3.0 Multi-channel share, are stuck reading documentation and with the CLI. On the networking side, MikroTik has a great UI, but for the storage side of the ROSE platform, it is just missing.
Next, let us get to the power consumption and noise.
