GMKtec EVO-X2 Power Consumption and Noise
The system came with a 19.5V 230W power adapter by HuntKey.
At idle, the system was great in the 8-14W range. That might be one of the big benefits of the integrated GPU. We also only measured 37-38dba at idle in our 34dba noise floor studio.
Running Llama 3.3 70B Q6_K inference, we saw 147-160W and would get into that 41-43dba range. Gaming, we were in the 170-180W range at 43-44dba.
The system was far from what we hear with loud systems. At the same time, I wish it was a bit quieter. Also, on the power consumption 170-180W from a single package with LPDDR5X memory is quite a bit.
Key Lessons Learned
To me, the big lesson learned was really on the AI side. We knew that the gaming performance was going to be very good just because it is a 40 CU RDNA 3.5 GPU. To me though, the gaming performance would not sell me on this machine at $1,999. There are too many other options in the market to hit this level of raw GPU performance.
What sells this system to me is very simple: 128GB of LPDDR5X, that 40 CU RDNA 3.5 GPU, and AMD’s ROCm support.
Partitioning the system with 64GB for the CPU and 64GB for the GPU or 32GB for the CPU and 96GB for the GPU completely changes the usefulness of the system. Running local 70b parameter models we saw the impact immediatley when we were filming of having larger higher quality models that provided useful results versus smaller faster models that ultimately gave us unusable output.
The hard truth about today’s generative AI is this: bigger models may be slower, but they are better. Or put another way, if you truly want to offload tasks to AI agents, you want to use the highest quality models possible. Speed is important too. We saw almost double the performance by switching from a partial CPU offload to a fully GPU accelerated model.
If you are doing AI, and are willing to give up some speed, then this is the lower-cost solution that can run models that are too big to fit in the memory footprint of a NVIDIA L40S. To be clear, the NVIDIA GB10 systems are going to be very neat in this space with their ConnectX networking built-in for clustering. Although we expect consumer/ Windows versions of the GB10 at some point, the 128GB AI version is going to be $3000+. AMD’s offering is available today, and at a lower cost. Perhaps AMD’s biggest competition right now for boxes like this is the Apple Mac Studio. The M3 Ultra 512GB version we have in the studio is simply awesome for AI, but it is also a $10,000 machine. Running large models on a $2000 device with up to 96GB dedicated for the GPU is actually quite a bargain if you view it form the angle of AI system and component pricing.
GMKtec had the wisdom to put this into a small package that can be powered on the desktop. I wish that at this price it also had things like 10GbE and the serviceability was a notch better. Still, the big value here is in the APU.
Final Words
From a system perspective the GMKtec EVO-X2 is in-line with what we have seen from other AMD Ryzen AI Max+ 395 systems, and it actually worked well in our testing. $2000 for a mini PC feels like a lot if you are looking for basic desktop functions or gaming. From an AI perspective, this is a really strong system.
Here is perhaps the crazy thought. If you have a regular task that can be automated by a 70b parameter model, or you want to run larger image or video generation AI tasks, the $2000 price might actually be a bargain. There is enough here that I do not think that this system is perfect, but also I really like this little box because it has some excellent capabilities.
It is a great system, but it’s been a while since I’ve seen such an ugly enclosure on a modern computer.
