For the Supermciro X7SPE-HF-D525 pfSense appliance I discussed in the linked post I of course wanted a chassis for my appliance and decided to purchase the CSE-502L-200B for just under $70 (see ebay and NewEgg). Oftentimes one does not need a massive chassis for a server. Frankly, with all of the mITX and mATX form factor boards out there, and all of the onboard features the boards have, there are a lot of applications where people do not need a large/ deep chassis. Using a shallower rackmount chassis allows one to use much smaller lightweight wall mounted network rack or telco post rack which saves a lot of space. As a result, for my Atom based pfSense appliance, I purchased a Supermicro CSE-502L-200B. Read the full story

I just wanted to update everyone on the Supermicro X7SPA-HF-D525 and X7SPE-HF-D525 review that was posted earlier as I have had a bit more time running the unit, especially as a pfsense appliance. Areas that will be looked at here are a higher-than-spec memory limit (4GB is not the max!), power consumption, and a word about IPMI 2.0 connectivity. Thus far, the network cabinet at home has been rock solid with the pfsense box managing routing duties in a fan-less configuration this week, even after I have been running a lot of network tests on the box. This is one I was able to justify purchasing for the new house which was great. Read the full story

The Supermicro X7SPA-HF-D525 and Supermicro X7SPE-HF-D525 boards reviewed today are somewhat unique, and let’s face it; fairly expensive Intel Atom based boards. Both boards are centered around an Intel Atom D525 dual core 1.8GHz chip that can handle up to four threads through Hyper-Threading. While an Atom D525 is a fairly standard part, especially when it comes to low power PC’s, Supermicro has done a lot to turn these boards into something suitable for server use.

For those wondering, the reason I am doing a split review here is because the X7SPA-HF-D525 and X7SPE-HF-D525 are both very similar boards. The “A” version is a standard mITX size board while the “E” version is slightly elongated to work with Supermicro’s CSE-502L-200B chassis and a 1U PCIe riser (review coming shortly as I purchased one of these also.) For practical purposes, the technical aspects are nearly identical aside from the size. Read the full story

As some readers know, a big reason for the slow content on the site is that I am busy writing a big piece on Intel vPro technology for a very big technology review site. As part of this, one thing I realized is that Intel’s current model of offering it only with specific chip sets and its mid to high end CPUs is quickly becoming obsolete. Read the full story

Over the past few months I have looked at a number of different CPUs including the Intel Atom Pineview D510 platform, the AMD Brazos E-350 platform, and a number of Xeon E3 series CPUs like the Xeon E3-1230. At the same time I have been playing with those CPUs and a lot of previous generation hardware with Microsoft Small Business Server 2011 Essentials and have some thoughts on hardware that I thought I would share. Read the full story

AMD’s Zacate E-350 is the culmination of the AMD-ATI merger’s synergy expectations. AMD rocked the press when it shared its vision of a unified CPU and GPU to attack at the heart of Intel’s GPU market dominance. Several years and chief executives later, that vision has been put into a shipping product, only about a year after Intel did the same. As many people know, I use relatively thin clients at each TV/ PC monitor to pull data and music from central storage servers so ultra low power clients are a major interest of mine on a personal note. Seeing other reviews, I was very excited about the Zacate E-350 as it promised better performance than Intel’s Atom D510 and D525 mainstay parts. Read the full story

A lot of comments have been logged asking for an entry/ low-end storage DIY guide. The purpose of this guide is to provide a solution for a system with 2-6 drives which is more robust than a simple 1-2 drive NAS system sold by many vendors. Unlike the higher-end and mid-range builds, this guide will optimize for cost of initial purchase as well as power consumption. It will be assumed that these systems are only running one operating system in a bare metal installation (i.e. these will not be virtualized systems). Read the full story

Yesterday Intel announced the Atom D425 and D525 platforms targeted for small storage servers. Both chips are 1.8GHz parts with Hyper-Threading. The Atom D425 is a single core with 512KB of cache (10w TDP) and the Atom D525 (13w TDP) being the dual core chip with 1MB of L2 cache.

The chips support both the DDR2 like the Atom D410 and Atom D510 did, but also support DDR3 SODIMMs. Generally speaking, DDR3 SODIMMs use slightly less power than their DDR2 variants. The TDP of the new chips is identical to the older D410 and D510 chips rated at 1.66GHz. Read the full story

As one would gather from my previous Intel Atom D510 and NM10 post, I am not the biggest fan of the current D510 Atom platform with NM10 chipset. ZOTAC, to its credit, did take a rather mediocre platform and build a solid board around it. The most probable use case is a streaming media HTPC (non h.264) to a legacy 720p display. The nice thing about the ZOTAC offering is that it has quite a few expansion options for a D510/ NM10 based system, and it is ready to go out of the box. Unlike other Intel and AMD platforms, the Atom D510 and accompanying heatsink do not need to be installed by the user. One can literally plug in a display, mouse, keyboard, RAM, storage drive(s), and 20-pin power source and start using the system. As a preview, my end conclusion is that the ZOTAC board is a great choice given the platform, but the Intel platform leaves a lot to be desired. Read the full story

As many have saw, Intel Corporation unvieled its new Atom platform for small business and home storage/ NAS products at CeBIT. It seems like this is not a Windows Home Server V2 (WHS V2) or Vail solution.
Read the full story
