Maximum Memory of the Haswell Intel Xeon E3-1200 V3 Series

4
Intel Xeon Logo
Intel Xeon Logo

For those that are wondering, the details on the Haswell based Intel Xeon E3-1200 V3 series processors are out. Again expect that Intel is limiting the Intel Xeon E3 platform to 32GB of RAM. There was broad hope within the community that the Intel Xeon E3-1200 V3 series CPUs would have a higher maximum memory limit. The Sandy Bridge and Ivy Bridge Xeon E3 platform also had a maximum of 32GB of RAM. Of note here, the Core i3, Core i5 and Core i7 Haswell processors will have the same maximum memory amount. Intel utilizes one common CPU architecture across both the mobile and desktop processors and the UP Intel Xeon E3 family. This is similar to what we saw with the Xeon 3500 series, and E3-1200 V1 and V2 series processors so there is no surprise there.

[pullquote_right]… the new Haswell chips can support 32GB at 1600MHz in its maximum memory configuration[/pullquote_right]As with previous versions, the Haswell Intel Xeon E3-1200 V3 series still utilizes unbuffered memory. It can accept either ECC or non-ECC memory. Larger capacity DIMM types such as Registered DIMMs or LRDIMMs will not work with the Haswell based Intel Xeon E3-1200 V3 series processors. As with previous generations, the Intel Xeon E3-1200 V3 series is a dual channel memory configuration and can therefore address up to four DDR3 DIMM slots. Memory speeds are the same as with the Ivy Bridge generations at a maximum of 1600MHz DDR3 memory. Each DIMM can be up to 8GB in size yielding a 4x 8GB = 32GB maximum memory amount for the Intel Xeon E3-1200 V3 series.

For those interested, it appears as the new Haswell chips can support 32GB at 1600MHz in its maximum memory configuration. Either single or dual ranked DDR3 UDIMMs can be used. In terms of board layouts, from what we have seen thus far, the Haswell based processors. More to come on the Haswell chips this week but suffice to say, users hoping for a boost to at least 64GB will either need to look at the Intel Core i7 (LGA2011 based), Intel Xeon E5 series or an AMD Opteron solution. In the meantime, we have already produced benchmarks of a retail Intel Core i7-4770 Haswell part.



4 COMMENTS

  1. Hi Patrick, you wrote in your review above:

    “…it appears as the new Haswell chips can support 32GB at 1600MHz in its maximum memory configuration”

    Does it mean that Ivy Bridge canNOT support 32BG at 1600MHz? Can Ivy Bridge on X9 Supermicro board support 32GB at 1600MHz, or does it only support 32GB at 1333MHz?

  2. Care to respond? I guess Patrick, your site here is just for traffic and ads. I can understand that too. Why bother wasting time on replying as long as the site is up and the posts are indexed by Google right?

  3. Hi. Generally this type of question will be quickly answered in the forums or by quickly searching Intel’s ARK. Have been on vacation for a bit so am still catching up while on the road. Forums are probably the best place to go for this information though.
